Front Service LED Display/Screen/Sign/Panel/Billboard (P6 Outdoor Fixed LED Display)

Basic Info

Model NO.	P6
Pixel Density	27777 DOT/M2
Scanning Mode	Static Scan
Display Type	LED Video Display
Application	Advertising
Certification	CE, RoHS, CCC
Cabinet Material	Iron
Best View Distance	6~150m
LED Chip Spec	SMD3535
Shipment Terms	by Sea or by Air
Control System	Nova or Xixun
Price	Factory Direct Sale
Brightness	6500-7500 CD/M2
Transport Package	Wooden Case
Specification	960mm*960mm*120mm
Trademark	GM
Origin	Shenzhen

Product Description

Front Service LED Display/Screen/Sign/Panel/Billboard (P6 Outdoor Fixed LED Display)Product Series: SMD3535 or SMD2727
Product Description
Full Color Outdoor P6 LED Sign/LED Screen for advertising with high brightness, good uniformity, good stability and good waterproof, become more and more popular on the market for its reasonable price and good display effect
Product Features:

1. SMD led encapsulation technology confirm the wide view angle up to 140 degree for horizontal and vertical, and good uniformity,less than 0.1mm difference

2.High quality leds with black body with high contrast,high brightness up to 7500nits

3. Good Waterproof IP65, can be used under heavy rain weather and humid area

4. Stability Iron cabinets for fixed installation, with fast lock and aviation plugs, conveninet to install and dismantle

5. High quality, meet the request of international standard of CE, FCC,RoHs

6. Long life span >100000hours, and 5 year warranty

Product Model	Outdoor Fixed F16-1S	Outdoor Fixed F10-2S	Outdoor Fixed F8-5S	Outdoor Fixed F6-8S
Pixel Pitch	16 mm	10 mm	8 mm	6 mm
Module Size	320x320 mm	320x320 mm	320x320 mm	192x192 mm
Module Resolution	20x10 pixels	32x32 pixels	40x20 pixels	32x32 pixels
LED	SMD3535	SMD3535	SMD3535	SMD2727
Standard Cabinet Size	960x960 mm	960x960 mm	960x960 mm	960x960 mm
Standard Cabinet Resolution	60x30 pixels	96x96 pixels	128x128 pixels	160x160 pixels
Standard Cabinet	Iron	Iron	Iron	Iron
Physical Density	3906 Pixels/m2	10000 Pixels/m2	15625 Pixels/m2	27777 Pixels/m2
White Balance Luminance	≥7000 nits	≥6500 nits	≥7000 nits	≥6500 nits
Gray Scale per Color	65536 grades gray(16 bit)	65536 grades gray(16 bit)	65536 grades gray(16 bit)	65536 grades gray(16 bit)
Contrast	5000:1	5000:1	5000:1	5000:1
Refresh Frequency	≥3840 Hz	≥3840 Hz	≥3840 Hz	≥3840 Hz
Visual Angle(Horizontal/Vertical)	140°/140°	140°/140°	140°/140°	140°/140°
Max Power	700 W/m2	600 W/m2	650 W/m2	800 W/m2
Average Power	220 W/m2	180 W/m2	200 W/m2	250 W/m2
Input Voltage(AC)	110 V -240 V	110 V -240 V	110 V -240 V	110 V -240 V
Working Environment Temperature	-20ºC~50ºC	-20ºC~50ºC	-20ºC~50ºC	-20ºC~50ºC
Operating Humidity	10%RH~95%RH	10%RH~95%RH	10%RH~95%RH	10%RH~95%RH
Control System	AV,Video,VGA,DVI,HDMI,SDI,DP	AV,Video,VGA,DVI,HDMI,SDI,DP	AV,Video,VGA,DVI,HDMI,SDI,DP	AV,Video,VGA,DVI,HDMI,SDI,DP

Product Features:

1. SMD led encapsulation technology confirm the wide view angle up to 140 degree for horizontal and vertical, and good uniformity,less than 0.1mm difference

2.High quality leds with black body with high contrast,high brightness up to 7500nits

3. Good Waterproof IP65, can be used under heavy rain weather and humid area

4. Stability Iron cabinets for fixed installation, with fast lock and aviation plugs, conveninet to install and dismantle

5. High quality, meet the request of international standard of CE, FCC,RoHs

6. Long life span >100000hours, and 5 year warranty

Why GM LED Display

1. Competitive Price
We are middle-sized Chinese local factory, maybe you can see that from our so Chinese name of "(GM) Meaning:Manufacturing golden quality , Towards the world ", unlike the internationalized name of foreign trade company. Besides, we control our cost very well and don't have huge management cost like top companies, so that we can give the real benefits to our customers.

2.Close Relationships with Raw Material Providers
For our bosses have been in the key positions at the top led display factory since 2006, we havevery close and strategic relationship with the raw material providers, which support the stable quality of our products.

3. Quality Control
From raw materials to finished product, from design to produce, we control all steps, which are the guarantee of the quality and reliability.

4. Professional services
We have 5-6 in the LED display industry more than 12 years of professional and technical personnel, hope to be able to better provide customers with the best solution. Let customers use the rest assured.

Other products:Indoor fixed LED screen: P2.5, P3, P4, P5, P6, P8, P10Indoor rental LED screen: P3, P3.9, P4, P4.8, P5, P6Outdoor fixed LED screen: P5, P6, P8, P10Outdoor rental LED screen: P3.9, P4.8, P5, P6, P6.25, P8, P10Small pitch LED screen: P1.6, P1.9Front service maintenance LED screen: P6.67, P8, P10Stadium perimeter LED screen: P8, P10LED poster player: P2.5,P3, P4, P5, P6, P8, P10

Services:

1.Your inquiry related to our products or price will be replied in 12hrs.

2.OEM&ODM,any your customized lightings we can help you to design and put into product.

3.Distributoership are offered for your unique design and some our current models.

4.Protection of your sales area,ideas of design and all your private information.

5.Best cost performance and perfect service before and after sales.

FAQ
1. How can i place an order?
Please inform your requirements as clear as possible. So we can send you the offer ASAP.it is better to contact us with Skype/email /phone within project begining, in case of any delays.
2. What kind of display we provide?
We have indoor/outdoor/mobile LED /rental LED display /LED stage/LED Dance Floor/Irregular LED display/stadium LED Display for you choose.
3. What about the lead time for order?
Always: 3-20 days, as your order quantity, sometimes we have stock, can delivery within 10 days
4.How about the warranty ?
2 years warranty.
5. What is your terms of delivery?
We accept EXW, FOB, CFR, CIF, DDU, etc. You can choose the one which is the most convenient or cost effective for you.

Packing>>>
For iron cabinet led display screen of indoor or outdoor,we usually use wooden case to packing
For aluminum cabinet of led rental stage display,we usuallu use flight case to packing
One wooden case including 2 cabinets,one flight case including 6 cabinets
Shippment>>>
By air or sea,FOB shenzhen
UPS/DHL/Fedex/Express(door to door)and so on
Delivery time>>>
within 20 days counting from 30% prepayment arrived at GM account.
Payment term>>>
T/T(30% deposit,the remained 70% payment made before factory shipment )
Western union/paypal/L/C and so on
Quality assurance>>>
We offer 5 years warranty,and our products have passd CE,RoHS,FCC certificate ,All products have Age testing,shaking testing,waterproof testing,In generally,Module test is 24h,entire screen test is 72h,A series of testing before delivery can ensure transportation and quality products.


FAQ
1:What is the warranty of your led display?
A:We offer 6 years warranty.and more than 100000 hours screen life span

2:what is your payment term?How long it takes to delivery?
A:We usually accapt the T/T or L/C.both of them will at least 30% deposit in advance,and the rest of 70% will paid before delivery.The lead time is usually 20 day

3:How can you ensure the led display product quality?
A:Before shippment,all the screens have aging test.and then we also have waterproof test and shake test,ensure products can transportation safety and normal use.

4:What is your pre-sale and post-sale service?
A:For pre-sale service,we have professional sales team and technical team,who are willing to answer your question within 24 hours.
For post-sale service,we will instruct you how toinstallation,how to use,how to change the broken moudles,and we can also send the technicals to your country,in general,our led display will not have a big problem,you can rest assured to buy.



Please send us inquiry in the Below Area, We will Provide you the High quality LED Screen Product with lowest price ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓
